INGENIA IG2TR
La serie INGENIA encarna una prolongada experiencia en acústica, mecánica, tecnología de amplificación y programación DSP, combinada con el talento y la intuición para crear un parlante activo sin precedentes: compacto, modular, suspendido, fácil de usar e increíblemente ingenioso.
Datos Técnicos
Speaker Type
2-Way Active Speaker
Datos Acústicos
Frequency Response [-10dB]
60 – 20.000 Hz
Frequency Response [-6dB]
65 – 19.600 Hz
Max SPL
128 dB
HF
1″
HF Voice Coil
1.4″
Directivity (HxV)
100 x 80° (+15°/- 65°)
HF Type
Neodymium compression driver
Horn
Vertical asymmetric
Crossover Frequency
1750 Hz
LF
2×8”
LF Voice Coil
2″
LF Type
Neodymium
Amplificador
Amp Technology
Digipro® G3
Amp Class
Class-D
Peak Power
800 W
RMS Power
400 W
User Interface
OLED display + rotative knob w/switch
Self-rotating display
Yes
Positioning
EPD (Element Position Detection)
Display Mirroring
Yes
Procesador
Controller
DSP 56 bit
AD/DA Converter
24bit/48kHz
System Presets
Factory presets + User defined
Limiter
Dual Active Peak, RMS, Thermal
DSP Processing
FIR Linear Phase
Sección de Entrada
Signal Input
1 x XLR/jack combo, 1 x RJ45 Link (RDNet),
1x USB (Data Service)
1x USB (Data Service)
Signal Out
1x XLR balanced, 1 x RJ45 Link (RDNet)
USB connector
Yes – mini USB
Mecánica
Housing
Polypropylene PP reinforced
Grille
FULL /Invisible screws
Flyable
Yes
Handles
1x on top / 1x on bottom
Pole Mount
Yes
Width
228 mm (8.98 in)
Height
646 mm (25.43 in)
Depth
315 mm (12.40 in)
Weight
12.8 Kg (28.22 lbs.)
